圆孔60度排列1:1 比例示意图

R0.8T1.6 OA23%
R1T2 OA23%
R1.2T2.5 OA21%
R1.5T3 OA23%
R2T3 OA40%
R3T5 OA33%
R4T6 OA40%
R5T7 OA46%
R6T10 OA33%
R8T12 OA40%
R10T15 OA40%
R15T20 OA51%

长圆孔及长方孔 1:1 比例示意图

长圆孔R1L10-Z7X14 OA20%
长圆孔R2L20-Z10X25 OA31%
长圆孔R3L20-Z14X26 OA32%
长圆孔R4L20-Z10X25 OA61%
长圆孔R4.75L20-Z15X25 OA48%
长方孔C1.25L20-U2.5X25 OA40%
长方孔C1.5L20-U3X25 OA40%
长方孔C2.25L20-U4.5X25 OA40%
长方孔C2.5L20-U5X25 OA40%
